OPT-DANTE
SKU: Various
Enable monitoring from up to a 64ch Dante™ Input. Hardware card with software activation key.
Description
Installing a Wohler unit with the Dante hardware option into an existing and functioning Dante network is virtually plug and play. The rear panel AoIP jack supports 1Gb/s and 100Mb/s Ethernet devices in Dante Audio over IP network configurations. Channel source selections are made by choosing Input Type ‘AoIP’ in the Configuration-Configure Presets page regardless of which AoIP option is installed. The iAM-series unit is set up at the Wohler factory to be used as a slave rather than a master within the Dante network. Other devices or software, such as a Dante Controller, are expected to be responsible for most device configurations and all audio routing.
This processing option can be installed in the products listed below and more information can be found in the manuals for these products:
| Dante Capable Unit | Option Part# | Description |
| iAM-12G-SDI | 829164 | Adds primary and secondary RJ-45 ports for hitless/2022-7 support (for Dante and 2110-30 signals). NMOS support is included. Also Includes OPT-MADI/ANLG/TOS option card (829168). |
| iVAM1-12G | 829171 | Adds primary and secondary RJ-45 ports for hitless/2022-7 support (for Dante and 2110-30 signals). NMOS support is included. Adds a Gigabit SFP cage allowing multi-mode and single-mode network SFP’s for AoIP Signals + optical TOSLINK input. |
| iVAM1-1 iVAM1-3 iVAM2-2 |
829171 | Adds primary and secondary RJ-45 ports for hitless/2022-7 support (for Dante and 2110-30 signals). NMOS support is included. Adds a Gigabit SFP cage allowing multi-mode and single-mode network SFP’s for AoIP Signals + optical TOSLINK input. |
| iAM-AUDIO-1-PLUS iAM-AUDIO-2-PLUS |
829171 | Adds primary and secondary RJ-45 ports for hitless/2022-7 support (for Dante and 2110-30 signals). Adds a Gigabit SFP cage allowing multi-mode and single-mode network SFP’s for AoIP Signals + optical TOSLINK input. |
| iAM1-8 iAM2-8 |
829171 | Adds primary and secondary RJ-45 ports for hitless/2022-7 support (for Dante and 2110-30 signals). Adds a Gigabit SFP cage allowing multi-mode and single-mode network SFP’s for AoIP Signals + optical TOSLINK input. |
| iAM-MIX8 iAM-MIX16 |
829078 | Primary RJ-45 port. |
It is also available on these end of life products:
- IAM-AUDIO-1 and IAM-AUDIO-2 – 16 Channel Audio-only Monitors, available in 1U or 2U (replaced by AUDIO-PLUS’s above)
- IAM-VIDEO-2-MPEG Carries MPEG over ASI with OPT-MPEG option (when used with iAM-VIDEO-2)
Features and Benefits
Options
A-V Specs
Physical Specs
| Shipping Dimensions | N/A (LxWxH) |
