Adds decoding and monitoring of a single MPEG2 Transport Stream (MPEG2/H.264) of max.15Mb/s chosen from an MPTS of max.200Mb/s, carried over ASI or IP.

Available for iAM-VIDEO-2 only.

• Video Codecs:
  H.264 / MPEG-4 AVC up to HD: [email protected], 4:2:0 8-bit
  MPEG-2 up to HD: [email protected], 4:2:0 8-bit
• Video Resolutions:
  1080P / 720P : 60 / 59.94 / 50 / 29.97 / 30 / 25 / 24 / 23.96 fps
  1080i : 30 / 29.97 / 25 fps
  SD : NTSC, PAL, VGA, QVGA, CIF, SIF, QCIF, QSIF
• Audio Codecs:
  Dolby E / D / DD+ (E-AC3), MPEG-1 Layer 1 / Layer 2, AAC-LC (*requires OPT-DOLBY)
• Audio Resolutions:
  Up to 48kHz audio
• Network protocols:
  MPEG-2 TS over UDP, SSM IGMPv3

Note that MPEG over ASI requires SFP-SDI (829089), SFP-SDI-Fiber (829084), or SFP-SDI-DUAL (829154)
