SKU: 8130-0300


The World’s Finest Audio/Video Monitor™. Modular upgradability. Includes Dolby D/E/DD+ & 1 x 3G/HD/SD-SDI module. 2RU.
Ask a Question

Ask a Question



Sold Out

Sorry this product is sold out / Out of Stock

$ 8395

Request a Quote

fields marked with an * are required


    First Name*

    Last Name*



    Company Name*

    Select Country*

    Please indicate the signals you need
    to decode or monitor


    Any additional processing needs?
    Wohler offers additional processing options.
    Please check any/all that you want quoted.

    Dolby D/DD+/EDolby ATMOSOutput Routing

    Please describe your project

    please provide project informaion to help us give you the best quote.
    Quantities and # of channels to monitor is especially useful.

    Budget Status

    Date Product is required

    Number of units required


    The leading choice of broadcasters worldwide, Wohler’s AMP2-16V could be the last audio monitor you will ever need.  The open architecture design, superb quality, upgradeability and ease of use is why broadcasters consistently choose the AMP2-16V Series monitors for their most demanding applications.

    Since we invented the in-rack audio monitor, we have not stopped improving it – and the world’s best selling and most powerful monitor now offers an even broader set of critical audio management tools.  Monitor and analyze all of your audio and video feeds from one compact, convenient and easy to use workstation.  It’s the best we’ve ever designed and built.

    Features & Benefits


    • Full 16 channels of simultaneous, mixed-format audio metering and management
    • Customize two large high resolution LCD screens to display application specific audio/video data
    • 32 presets enable complete reconfiguration of the entire unit with a single button press
    • Added support for SMPTE2020 metadata handling, audio delay and loudness monitoring
    • Measure Audio Loudness using ITU-R BS.1770 or EBU R128 standards
    • Mix, sum and route program audio live without the need for separate audio console
    • Save and copy system presets to other units via Ethernet/Serial connection to PC


    • Monitor, mix, route and fully manage SDI embedded audio, AES, analog or even TOSLINK sources
    • Ability for re-embedded audio in SDI output
    • Dual LCD screens with auto-detecting 3G/HD/SD-SDI video
    • 16 Hot Keys enable one touch access to critical functions
    • Fully-customizable level meters including scale, color, range, thresholds, and more
    • Single screen view of 16 channel meters/clusters, phase indication, loudness, Dolby D, E, and DD+ presence and hot key assignments
    • Menu lockout function and redundant power supplies for secure transmission chain operation (optional)
    • “Super-Pair” feature offers additional channel pair (17, 18) to monitor additional two intercom or PL intercom channels


    A-V Specs

    Spkr Power Output  RMS Each Side: 15W Continuous/30W Peak
    Peak Acoustic Output @ 2 feet  104 dB SPL @ 2 ft
    Frequency Response  60 Hz – 16 kHz (+/-5 dB); (-10 dB @ 50 Hz, 20 kHz)
    Hum and Noise  Better than -75 dB below full output
    Meter Dynamics  Configurable up to simultaneous VU & PPM
    Number of screens  1
    Diagonal Display Size  4.3 Inch
    Display Resolution (HxV)  800 x 480


    Physical Specs

    Rack Height  2RU
    Power Consumption  250 Watts Max
    Power Supply  Internal IEC Connector, Universal Input, 100-240VAC, 50/60Hz, CE & UL approved.
    Dimension Width  19.0″ (483mm)
    Dimension Height  3.5″ (89mm)
    Dimension Depth  14.5″ (369mm)
    Net Weight  21.0 lbs (9.6 kg)
    Shipping Weight  21.0 lbs (9.6 kg)
    Shipping Dimensions  24.0 × 19.5 × 7.5 in (LxWxH)
