|Signal Licensing Options (software only, no hardware)
||Enables decoding and monitoring of 4 x AES inputs, 1 AES Output
||Enables decoding and monitoring of 1 x MADI64 input via BNC
|Processing Options (software only)
||Enable monitoring of Dolby D, DD+ or E streams. Software activation key. Functions on SDI via BNC, or any of the following OPT/SFP’s: OPT-AES, SFP-SDI-Fiber, SFP-2022-6, SFP-2110, and SFP-2110+2022-6
||Enables the flexibility to route input signals to various outputs.
|Option Cards for Signal I/O Processing (includes hardware)
|This AoIP option card enables decoding and monitoring of up to 64 ch of DanteTM OR Ravenna™ / AES67/ 2110-30 Input streams with NMOS Support. These option cards provide 2 x RJ-45 ports for 2022-7 support + SFP cage allowing MM and SM SFP’s as an alternate primary for AoIP Signals. TOSLINK included in both cards.
||Enable monitoring of 8 analog channels on DB-25. Hardware card with software activation key. Includes Optical TOSLINK input.
||Adds two additional 3G inputs to 3G products, or two 12G inputs to 12G products.
|Small form-factor pluggable (SFP) Options
|SFP-2110 w/Ember+ (or NMOS)
||Receiver, Multi-Mode 850 NM, LC (fiber) Connectors. Use 829086-1 for NMOS variant.
||Receiver, LC (fiber) Connectors
|SFP-2110 w/Ember+ (or NMOS) + 2022-6
||Receiver, Multi-Mode 850 NM, LC (fiber) Connectors. Use 829087-1 for NMOS variant.
||3G/HD/SD-SDI single video receiver with active loopback. HD-BNC Connectors. Only purchase if 3rd SDI I/P is required.
||SDI single mode Optical LC (fiber) video receiver. Up to 12G-SDI capable depending on base unit
||3G/HD-SD-SDI Transceiver, HD-BNC connectors, I/P and O/P are both SDI
|SFP-MADI-Fiber (MM or SM)
||MADI optical fiber transceiver; Multimode or Singlemode, LC (fiber) Connectors. Use 829081 for Multimode (MM). Use 829082 for Singlemode (SM).
