SKU: 8001-0630


32″ 12-bit Ultra HD LCD screen supports up to 4 channels of 3G/HD/SD-SDI. 1920x 1080 resolution. In-screen audio level meters. Tabletop Stand.

Data Sheet


Ask a Question


Request a Quote

fields marked with an * are required


    First Name*

    Last Name*



    Company Name*

    Select Country*

    Please indicate the signals you need
    to decode or monitor


    Any additional processing needs?
    Wohler offers additional processing options.
    Please check any/all that you want quoted.

    Dolby D/DD+/EDolby ATMOSOutput Routing

    Please describe your project

    please provide project informaion to help us give you the best quote.
    Quantities and # of channels to monitor is especially useful.

    Budget Status

    Date Product is required

    Number of units required


    The HDM-320-4K-TT monitor sets a new standard in UltraHD LCD monitors for broadcast and professional video applications. It provides a 32”, 1920 x 1080 resolution, 16:9 format, 60Hz refresh, anti-glare IPS LCD screen. All video formats are scaled to fit on the screen in the highest quality using 12-bit digital processing, precision scaling and gamma correction to produce the best images possible.

    Features & Benefits

    • Monitor 2SI Interleave or Quad-Link 4K video using four HD-SDI inputs together.
    • Two display modes: single display and quad link display.
    • Each of 4 SDI inputs can be displayed by full screen in single mode. Quad link mode supports 2-SI and square division display.
    • User defined hot key functionality for either H/V delay, underscan, on-screen display.
    • On-screen, 16-channel level metering provides audio confidence monitoring.
    • Tally and on-screen labeling provide quick and easy signal identification.
    • CRT-style image controls allow video image enhancement for each screen individually.
    • Supports multi-format analog and digital audio signals.
    • Allows adjustment of the parameters for each screen.
    • User-adjustable color temperatures with presets.
    • Ethernet, RS-485 and GPI control interfaces.


    A-V Specs

    Meter Dynamics  VU or PPM or both
    Display Type  Active color matrix amorphous LCD IPS with LED Backlight
    Number of screens  1
    Color Depth  1.073G colors
    Diagonal Display Size  32″ Diagonal
    Native Aspect  16:9,4:3
    Display Resolution (HxV)  1920 H x 1080 V
    Viewing Angle  178° x 178°
    Contrast  3000:1
    Luminance  300 cd/m2


    Physical Specs

    Rack Height  13RU
    Power Consumption  44 Watts
    Power Supply  Internal IEC Connector, Universal Input, 100-240VAC, 50/60Hz, CE & UL approved.
    Dimension Width  28.3″ (720mm)
    Dimension Height  17.4″ (442mm)
    Dimension Depth  2.8″ (78mm)
    Net Weight  29.0 lbs (13.2 kg)
    Shipping Weight  29.0 lbs (13.2 kg)
    Shipping Dimensions  N/A (LxWxH)
